Additional information
| Weight | 1.1 kg |
|---|---|
| Dimensions | 44 × 20.5 × 6 cm |
| Wide operating frequency | 698–4000 MHz |
| Horizontal beamwidth | 90° (698–960 MHz), 75° (1710–2700 MHz), 54° (3300–4000 MHz) |
| Vertical beamwidth | 66° (698–960 MHz), 58° (1710–2700 MHz), 42° (3300–4000 MHz) |
| Power Handling | 50W |
| High gain | 9.5 dBi (698–960 MHz), 11.0 dBi (1710–2700 MHz), 11.5 dBi (3300–4000 MHz) |
| VSWR | <2.0:1 (698–960 MHz), <1.5:1 (1710–2700 MHz), <1.8:1 (3300–4000 MHz) |
| Polarisation | Vertical (linear) |
| Front-to-back ratio | >15 dB |
| Passive Intermodulation (PIM) | -153 dBc (3rd order, 2 x 20 W) |
| Lightning Protection | DC grounded |
| Ingress Protection | IP65 (weatherproof) |
